ESC Features:
– FOC (Field-Orientated control technology)
– Live tunning on Furicar app
– Super slow and ridiculously smooth throttle control
– New firmware algorithm to consistently smooth up the start up to FOC stage
– Work with Brushed/Brushless motors (config via app, default is brushless)
– Small size and light weight
– Super easy programming via App on both Android and iOS
– Real-time telemetry up to 10Hz
– Bluetooth module controlled by Furicar App included
– Waterproof and dustproof with an enclosing CNC aluminum case
– Over-temperature and max current protection
– AUDIBLE ALERTS for easy diagnosis of common issues such as motor-over-temperature and low-voltage cutoff.
– FREE lifetime firmware updates
Motor Features
– High low-end torque
– Low KV rating provides more torques at low speeds.
– Efficiency cooling system
– High-quality material with reliable magnets and durable bearings
– High-end CNC aluminum case
– Special designed 12S-14Pole Outrunner brushless motor for high torque output
– Super quiet, high torque, powerful and super slow speed yet tons of wheel speeds when needed
– High purity and higher temperature copper windings -lower copper losses, very good heat dissipating-maximizes efficiency.
– Super thin stator laminations—lower eddy losses—maximizes efficiency. High RPM ABEC5 bearings.
– Precision balanced rotor, smoothness for best reliability, and maximum RPM.
ESC Specifications:
– Supports 2-4S lipo batteries
– Selectable 5.5V/7.5V/8.4V (8A peak) BIG internal BEC (Battery Eliminator Circuit), (config via app)
– Constant current: 80A
– Burst current: 120A
– Removable ON/OF switch
– Dimensions: 1.7x 1x 0.4 (inch), 45x25x10 (mm)
– Weight: 41g (1.4oz)
Motor Specifications:
– Motor type: outrunner
– KV (RPM/V): 2000
– No-load current @7.4V : 3.0A
– Watt: 680W
– Battery: 3-4S lipo
– Resistance: 0.025Ohm
– Max current: 53A
– Slot/Pole: 12S14P
– Motor size: 28.5×38.5mm diameter
– Weight: 91g
Extra requirements:
– The new FURITEK brushless system needs a channel 2 from the receiver to connect to the external ESC. The stock TX/RX does not have a channel 2 so it is required to have a new at least 2-channel TX/RX
